10-year warranty. Safe, high performance. Fast shipping.
Cost-effective Double Face Temperable Mirror
Min. Order: 1000
Reference FOB Price: 15USD
Safe and high performance
The top temperature 675ºC-680ºC
The bottom temperature 670ºC-675ºC
Heating time 5mm  225-250S
Convection (Upper) Heating Time
Section 1 30%  5Hz
Section 2 25%  6Hz
Section 3 45%  8Hz
Note: 1) 5-10 ºC lower  in front and back than in middle furnace.
2)Contacting with corrosive chemicals is not allowed.
3) Cleaning by soft brush&neutral water.
4) Removing  the stains on coating by alcohol.

Description

Reviews

Our Double Face Temperable Mirror has obtained European CE certification, and has passed Reach, Rohs, and Svhc tests by SGS. This shows that our double face temperable mirror meets the highest European requirements. We are one of the few companies in the country that has passed all tests and certifications.

Double Face Temperable Mirror

Our Double Face Temperable Mirror is a new generation of environmentally friendly mirror that does not require back paint and can be tempered. It has strong processability and good alkali resistance. It can with stand high temperatures, can be flat and bent tempered, laminated, and has a wide range of product applications

SPECIFICATIONS:

Glass Color low iron, bronze,grey,etc.
Thickness 3mm,4mm, 5mm, 6mm,8mm,10mm,12mm
Normal Sizes(mm) 2140*3660MM, 2250*3660MM,2440*3660MM,
Quality Standard EN1036-2:2008/Reach, Rohs, Svhc test by SGS
Application Splashbacks Furniture Elevators Bathroom Mirrors Wall cladding Mirrors Guarding, balustrades and balcony partitions
MOQ 1000SQM, can mix with other glass in a container
Package Plywood Crates with paper/ powder interleaving

Data Sheet of double face temperable mirror:


Optical parameters

Glass surface Y=80.68 L=92.00
Toughened Glass Y=79.2 L=91.8
Double Face temperable mirror toughening parameters (reference only)

The top temperature 675ºC-680ºC
The bottom temperature 670ºC-675ºC
Heating time 5mm  225-250S
Convection (Upper) Heating Time
Section 1 30%  5Hz
Section 2 25%  6Hz
Section 3 45%  8Hz
Note: 1) 5-10 ºC lower  in front and back than in middle furnace.
2)Contacting with corrosive chemicals is not allowed.
3) Cleaning by soft brush&neutral water.
4) Removing  the stains on coating by alcohol.
